Vesta® Seri Tunable White Gen 2 6mm Etalaj
Bridgelux® Vesta® Seri Tunable White Gen 2 6mm etalaj
Dekri teren
Bridgelux® Vesta® Seri Tunable White Gen 2 6mm etalaj
Etalaj Bridgelux yo se aparèy konplètman enjenyè ki bay pèfòmans tèmik ak optik konsistan sou yon platfòm mekanik enjenyè. Etalaj yo enkòpore plizyè karakteristik pou senplifye entegrasyon konsepsyon ak asanble.
|
Fanmi pwodwi |
Pwodwi |
Nimewo Pati |
Nimewo Doc |
LES Size (mm) |
Typ. Flux (lm) |
Si (mA) |
Vf (V) |
Pouvwa (W) |
Efikasite (lm/W) |
Gwosè substrate (mm) |
Ranje CCT (K) |
CRI |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BXRV Vesta TW | Vesta Tunable Blan 6mm | BXRV-TR-2750G 06A0-B-2x | DS349 | 6.8 | 610 | 150 | 38 | 5.7 | 110 | 12.5x12.5 | 2700-5000 | 93 |
| BXRV Vesta TW | Vesta Tunable Blan 6mm | BXRV-TR-2765G-06A0-B-2x | DS349 | 6.8 | 615 | 150 | 38 | 5.7 | 111 | 12.5x12.5 | 2700-6500 | 93 |
| BXRV Vesta TW | Vesta Tunable Blan 6mm | BXRV-TR-1840G-06A0-B-2x | DS349 | 6.8 | 580 | 150 | 38 | 5.7 | 105 | 12.5x12.5 | 1800-4000 | 93 |
Tablo 1:Gid Seleksyon, Done Mezi
|
Nimewo Pati |
Nominal CCT 1 Tc=85 degre (K) |
Tipik CRI2 Tc=85 degre |
Nominal Kondwi Kouran pou chak chanèl (mA) |
Tipik Vf 3 Tc=25 degre (V) |
Tipik Pouvwa Tc=25 degre (W) |
Tipik Enpulsyonèl Flux 3, 4, 5 Tc=25 degre (lm) |
Tipik Efikasite5 Tc=25 degre (lm/W) |
Minimòm Enpulsyonèl Flux8 Tc=25 degre (lm) |
Tipik DC Flux7, 8 Tc=85 degre (lm) |
|
BXRV-TR-2750G 06A0-B-23 |
2700 |
93 |
150 |
37 |
5.6 |
530 |
95 |
477 |
456 |
|
5000 |
92 |
150 |
37 |
5.6 |
610 |
110 |
549 |
519 |
|
|
BXRV-TR-2765G-06A0-B-23 |
2700 |
93 |
150 |
37 |
5.6 |
530 |
95 |
477 |
456 |
|
6500 |
92 |
150 |
37 |
5.6 |
615 |
111 |
554 |
523 |
|
|
BXRV-TR-1840G-06A0-B-2X |
1800 |
93 |
150 |
37 |
5.6 |
350 |
63 |
315 |
305 |
|
4000 |
92 |
150 |
37 |
5.6 |
580 |
105 |
522 |
499 |
Tablo 2: Tablo pwodwi ki anrejistre nan Rejis pwodwi Ewopeyen an pou etikèt enèji (EPREL)
|
|
CCT (K) |
CRI |
Cur- lwaye 3 (mA) |
Volt- laj 3 (V) |
Itil Flux2 itil Tc=85 degre (lm) |
Pouvwa (W) |
Efikasite (lm/W) |
Enèji Efikasite Klas4 |
Regis- trasyon Non |
|
|
|||||||||
|
BXRV-TR-2750G-06A0-B-23 |
5000 |
90 |
200 |
36.33 |
653 |
7 |
89 |
G |
876352 |
|
BXRV-TR-2765G-06A0-B-23 |
6500 |
90 |
200 |
36.33 |
659 |
7 |
90 |
G |
879088 |
|
BXRV-TR-1840G-06A0-B-23 |
4000 |
90 |
180 |
35.79 |
576 |
6 |
89 |
G |
890639 |
Pati Nimewo
Tablo 3:Karakteristik elektrik
|
Nimewo Pati |
CCT |
Nominal Kondwi Kouran (mA) |
Pi devan Voltage Enpulsyon, T = 25 C (V) 1, 2, 3, 7 |
Tipik Tanperati Koefisyan nan Forward Voltage4 ∆Vf/∆Tc (mV / degre) |
Tipik Tèmik Rezistans Junction to Ka5 Rj-c (degre /W) |
Seleksyon Chofè Voltages6 (V) |
|||
|
Minimòm |
Tipik |
Maksimòm |
|||||||
|
Vf Min. Cho Tc = 105 degre (V) |
Vf Max. Fwad T = -40 degre (V) |
||||||||
|
BXRV-TR-xxxxG- 06A0-B-2X |
1800/2700 |
150 |
34.8 |
37.0 |
39.2 |
-10.6 |
2.1 |
33.9 |
39.9 |
|
4000K/5000/6500K |
150 |
34.8 |
37.0 |
39.2 |
-11.1 |
33.9 |
39.9 |
||
Tablo 4: Evalyasyon maksimòm
|
Paramèt |
Maksimòm Rating |
|
|
Tanperati Junction ki ap dirije (Tj) |
125 degre |
|
|
Tanperati Depo |
-40 degre a +105 degre |
|
|
Tanperati ka opere 1 (Tc) |
105 degre |
|
|
Tanperati soude2 |
350 degre oswa pi ba pou yon maksimòm de 6 segonn |
|
|
Maksimòm Kondwi Kondwi Kouran4 |
200mA |
|
|
Chèn 1 1800K/2700K |
Chèn 2 4000K/5000K/6500K |
|
|
Maksimòm Drive aktyèl pou chak chanèl3,4 |
200mA |
200mA |
|
Maksimòm Pik Enpulsyon Drive Kouran pou Pa Chèn5 |
240mA |
240mA |
|
Maksimòm pouvwa total |
7.4W |
|
